Product Data:
| Model | JF-C34-M |
| Name | 2 Doors Office Wardrobe Cupboard |
| Product Size | H1850 * W900 * D400mm |
| Package Size | H1890 * W490 * D107=0.0991CBM |
| Loading Qty | 658 Pcs/40’HQ, 282 Pcs/20’GP |
| Material | Heavy gauge cold-rolled steel plate. |
| Pre-treatment | Water wash, chemical wash, phosphating. |
| Finish | Durable electrostatic powder coating. |
| Colour | Classic grey, two-tone option, or other customized colour. |
| Fittings | Chrome coat rod, index holder. |
| Accessories | 2 keys, assembly screws. |
- Knock down and easy assembling construction.
- Different locks for option.
- Different colour for option.
- With huge loading capacity for each shelf.
- Reinforced doors for strength.
- Master key available.
8 steps to assemble the Metal Wardrobe Cabinet.
- Connect the left side plate with back plate by self-tapping screws(5×12).
- Connect the right side plate with back plate.
- Fix the door frame onto both of the side plates.
- Install the top plate, big shelf and bottom plate respectively.
- Install the division plate.
- Install the small shelves.
- Install the hanging rod.
- Adjust each part till fit well after installation.
